Yamaha MG10X CV 10 Channel Stereo Mixer (Used)

Original price was: $208.79.Current price is: $117.82.

Sale!
SKU: YMHA-MG10XCV-BA Category:
Share

Like New: Open box product with no signs of use.

Yamaha MG10X CV 10 Channel Stereo Mixer

Housed in a rugged steel chassis, the MG10X CV canaccommodate up to 10 inputs and offers a balanced stereo output. FeaturingD-Pre discrete Class A microphone preamplifiers for pristine sound, it includesan Aux bus for the built-in SPX effect with 24 presets and 2 channels of singleknob compression. The MG10X can accept XLR, ¼” Phone and RCA type pin jackinputs, and offers XLR and Phone outputs. The MG10X offers rotary controlsinstead of faders, reducing the footprint for discrete placement onstage oranywhere space is a premium. A footswitch input allows hands free effectmuting.

Key Features

  • Rugged, Powder-coated steel chassis for superior durability
  • Discrete Class-A microphone preamps
  • Built-in SPX digital effects with 24 programs
  • Switchable +48V Phantom power
  • Color coded controls offer easy operation

Technical Specifications

Frequency Response Input to STEREO OUT
+0.5 dB/-1.5 dB (20 Hz to 48 kHz), refer to the nominaloutput level @ 1 kHz, GAIN knob: Min
Total harmonic distortion (THD+N) Input to STEREO OUT
0.02 % @ +14 dBu (20 Hz to 20 kHz), GAIN knob: Min
Hum & Noise (20 Hz to 20 kHz)
Equivalent Input Noise
-128 dBu (Mono Input Channel, Rs: 150 Ω, GAIN knob: Max)
Residual Input Noise
-102 dBu (STEREO OUT, STEREO master knob: Min)
-102 dBu (STEREO OUT, STEREO master fader: Min)
Crosstalk (1kHz)
-78dB
Input Channels
Mono
4
Mono/Stereo
0
Stereo


  • 3
    Output Channels
    STEREO OUT
    2
    MONITOR OUT
    1
    PHONES
    1
    AUX SEND
    1
    GROUP OUT
    0
    Bus
    STEREO
    1
    GROUP
    0
    AUX SEND
    1 (incl. FX)
    Pad (Mono)
    26dB
    HPF (Mono, Mono/Stereo)
    80 Hz, 12 dB/oct (Mono)
    Input Channel Function
    COMP (Mono)
    1-knob compressor (Gain/Threshold/Ratio) Threshold: +22 dButo -8 dBu, Ratio: 1:1 to 4:1, Output level: 0 dB to 7 dB Attack time: approx.25 msec, Release time: approx. 300 msec
    High
    Gain: +15 dB/-15 dB, Frequency: 10 kHz shelving
    EQ Mid
    Gain: +15 dB/-15 dB, Frequency: Mono 250 Hz – 5 kHzpeaking,Stereo 2.5 kHz peaking
    Low
    Gain: +15 dB/-15 dB, Frequency: 100 Hz shelving
    Peak LED (mono)
    LED turns on when post EQ signal reaches 3 dB below clipping
    Level Meter
    Pre-Monitor Level Meter
    2 x 7 -segment LED meter

    Internal Digital Effect
    SPX Algorithim
    24 programs
    Phantom Power Voltage
    +48V
    Power Requirements
    PA-10 Power adapter (included)
    Power Consumption
    22.9W
    Dimensions (W x H x D)
    244 mm x 71 mm x 294 mm
    9.6”x 2.8”x 11.6”
    Net Weight
    2.1 kg (4.63 lbs.)
