PureLink VIP-T300-D 4K HDMI and USB/KM over IP Decoder
The VIP-T300-D 4K HDMI & USB/KM over IP Decoder providesUltraHD/4K video, audio, RS-232, IR, and USB signal transport over IP networks.The VIP-T300-D can be used as a point-to-point extension system supportingdistances up to 300 meters, as well as layered distribution, switching, andmatrix switching systems using multiple control options including PureLink’sVPX IP Video Management Software.
Key Features
- Ultra-low latency (<17mS)
- Max data rate 250Mbps;
- Fiber or CAT transport – 1G port
- Extend signals up to 300 m. using a network switch
- HDCP 2.2 compliant
- Comprehensive diagnostics via the front panel and API -device discovery, signal data, and EDID
- Supports instant switching
- Multiple control interfaces – built-in web interface, frontpanel buttons, IR remote control, VPX Management Software, Crestron module, and3rd party control development via API
- Built-in video wall processing (up to 8×8)
- Built-in scaler on the receiver (decoder)
- Image rotation 0, 90, 180 degrees
- IR and RS232 extension
- TCP/IP to RS232 conversion
- USB 2.0 for keyboard/mouse, camera, or hard drive
- HDMI loop-out on TX (encoder)
- PoE 802.3af (under 5W)
- Supports Dolby, DTS, and LPCM audio
- Matrix switching systems up to 999 sources and 65K displays
- TAA compliant
Technical Specifications
Hardware
Input Signal Type(s)
(1) 3.5mm Mono Phone Jack
(2) USB 1.1 Type A
(2) USB 2.0 Type A
RS-232 (DB9 Male)
Ethernet (RJ45)
Fiber SFP (1G
Output Signal Type(s)
(1) HDMI Type-A 3.5mm
Stereo Phone Jack
Performance
Supported Distance
150M (up to 300M using Network Switch)
Supported Resolutions
up to 4K@30Hz (4:4:4)
Compliance
HDCP 2.2
Supported Audio Formats
Up to 7.1 LPCM 192Khz
Dolby True HD
DTS-HD Master Audio
ATMOS
DTS:X
Power Consumption
500mA (Typical, No USB Device)
Power Supply
DC 12V 1500mA
PoE (Power Over Ethernet)
802.3af
Enclosure
Product Dimensions
6.5” x 4.0” x 1.5”
Product weight
1.1 lbs.
Warranty
Limited Warranty (3-Years)
