Passive 12″ Full-Range Loudspeaker
- Vertical and horizontal use thanks to a coaxial design with rotating, BEM-optimised CD horn (patent pending)
- Speaker Twist In/Out
- 4 Handles
- HF driver: 1″
- Power rating: 250 W RMS, 1000 W peak
- Impedance: 8 Ohm
- Frequency range: 55 – 20000 Hz
- Dispersion angle: 90° x 50°
- Peak SPL: 123 dB
- 2 x 36 mm Stand flange mount (0° and 5°)
- Monitor angle: 55°
- 6 x M10 rigging points
- Dimensions (W x H x D) 375 x 635 x 396 mm
- Weight: 19.8 kg
- Colour: Black
- Suitable cover: Article no. 481069 (not included)
3030-Day Money-Back Guarantee33-Year Thomann Warranty
- Available sinceJuly 2020
- Item number497290
- Sales Unit1 piece(s)
- Manufacturers Information Power Handling 1000 W
- Impedance 8 Ohms
- Number of Woofers 1
- Woofers in Inch 12″
- Colour Black
- Width 375 mm
- Depth in mm 635 mm
- Height 396 mm
- Weight in kg 19,8 kg
- Monitor Angle Yes
- IP Class None
- RMS Power250 W
- FlyableM10
- Impedance in Ohms8 Ohms
- SPL in dB123 dB
- Maximal SPL123 dB
- Number of Midrange Speakers0
- Number of Mid-Tone Speakers0
- Mid-Tone Speakers in Inchnone
- Number of HT-Speaker1
- Number of HT-Speakers1
- Stand Flange36 mm
- HT-Speakers in Inch1″
- Number of Ways2-Way
- Housing MaterialPlastic
- ConstructionStandard Cabinet
- Frequency Range (-3dB) from55 Hz
- InputSpeaker-Twist
- Frequency Range (-3dB) to20000 Hz
- OutputSpeaker-Twist
- Horizontal Beam Angle90 °
- Vertical Beam Angle50 °
