JTS CX-506 Condenser Drum and Percussion Cardioid Microphone
With a smooth uniform frequency response, the JTS CX-506 is optimizedfor use with drums and percussion instruments.
Key Features
- The unique design and miniature profile provide for minimalphysical size interference for the musician.
- Low noise electronic circuitry together with balanced outputprovides isolation from ambient noise.
- The shock mount clamp greatly reduces extraneous mechanicalnoise and ensures secure mounting on drum rims, percussion instruments, andcymbal stands in either a horizontal or vertical position.
- Excellent natural reproduction of drums and percussion,accurately and purely without coloration.
- Newly added spider suspension isolates unwanted mechanicalvibration effectively.
Technical Specifications
Type
Electret Condenser
Frequency Response
50~18,000 Hz
Polar Pattern
Cardioid
Sensitivity (at 1,000Hz)
-64dB*(0.63mV) at 1,000 Hz
Output Impedance
220Ω ± 30%
Max. SPL for 1% THD
130 dB
Output connector
3P. XLR (M) type
Net Weight
Metallic enamel-painted die cast metal body
with hardened, matte-finished steel grille
Net Weight
230 grams (8.1 oz)
Touch Noise
Super low
Power Supply
9-52V phantom power
