Behringer ADA8200 8-Channel ADAT Audio Interface with Midas Preamplifiers
The Behringer ADA8200 is an eight channel ADAT audio interface designed for digital recording, studio expansion, and live audio production systems. It enables audio engineers and producers to expand the input and output capabilities of their digital audio workstation or digital mixer through optical ADAT connectivity. This makes it ideal for studio environments where additional microphone preamps and analog to digital conversion are required.
The interface provides eight Midas designed microphone preamplifiers with phantom power and high quality Cirrus Logic twenty four bit converters. It converts analog microphone or line signals to digital audio through the ADAT optical output and routes ADAT signals back to analog outputs for monitoring or signal routing.
In practical setups, the ADA8200 can expand the input count of audio interfaces, digital mixers, and recording systems. External clock synchronization and ADAT connectivity allow it to integrate into a wide variety of studio and live recording workflows.
Key Features
- Eight Channel ADAT Interface: Provides 8 inputs and 8 outputs for digital recording and mixing environments
- Midas Microphone Preamplifiers: Eight high quality Midas designed mic preamps for professional audio capture
- 24 Bit Converters: Reference class Cirrus Logic A/D and D/A converters for accurate signal conversion
- Phantom Power Support: Phantom power available on all microphone inputs
- Optical ADAT Connectivity: ADAT optical input and output for digital audio routing and expansion
- Flexible Sample Rates: Supports 44.1 kHz and 48 kHz operation
- External Clock Sync: Synchronization through word clock or ADAT input
- Studio Expansion: Mic and line inputs routed to ADAT output and ADAT input routed to analog line outputs
- Universal Power Supply: Auto switching power supply supports 100 to 240 volt operation
Technical Specifications
Interface Type
8 channel A/D and D/A audio interface
Microphone Preamplifiers
8 Midas designed microphone preamps
Phantom power on all microphone inputs
Converters
Cirrus Logic 24 bit A/D and D/A converters
Sample Rates
44.1 kHz
48 kHz
Digital Interface
Optical ADAT input
Optical ADAT output
Clock Synchronization
External synchronization via word clock
ADAT input clock synchronization
Signal Routing
All mic and line inputs routed to ADAT output
ADAT input routed to all line outputs
Power Supply
Switching power supply
100 to 240 V AC universal input
